Galvanized Low Carbon Steel Wire
Low carbon steel wire is used as power cables. Here introduce the steel wire physical and mechanical specifications.
Zinc coated (galvanized) low carbon steel wires used as power Cables.
| Standard | BS 1442 | Weldability |
|---|---|---|
| Surface | Smooth | Uniformity of coating |
| Packing | On coils about 65 ± 5 kg | Adherence of coating |
| Property | 1.25 | 1.60 | |
|---|---|---|---|
| Diameter (mm) | Min. | 1.22 | 1.57 |
| Max. | 1.28 | 1.63 | |
| Tensile Strength (N/mm2) | Min. | 340 | |
| Max. | 500 | ||
| Elongation (%) | Min. | 10 | |
| Zinc coating (g/m2) | Min. | 200 | 230 |
Zinc coated (galvanized) steel wire used as messenger in self supporting telecom cables.
| Standard | DIN 2078 | Weldability | |
|---|---|---|---|
| Surface of wire | Smooth | Uniformity of coating | |
| Packing | On reels about 400-430 kg | Adherence of coating | |
| Property | 1.20 | 1.60 | |
|---|---|---|---|
| Diameter (mm) | Min. | 1.17 | 1.57 |
| Max. | 1.23 | 1.63 | |
| Tensile Strength (N/mm2) | Min. | 1650 | |
| Elongation (%) | Min. | 5 | |
| Zinc coating (g/m2) | Min. | 170 | 200 |
